PRODUCT FEATURES
1.Material: AISI302, 304,316,316L,310S,410,430,904L,2205,2507,etc
2.Wire Diameter: 0.015-2.8mm
3.Mesh count:
Plain weave can be woven up to 400 mesh.
Twill weave can be woven from 400 to 635mesh.
Dutch weave can be woven up to 3500mesh
4.Weave pattern: Plain Weave ,Twill Weave,Dutch Weave,etc.
| Stainless steel wire mesh | ||
| Mesh | Dia mm | Hole mm |
| 2MESH | 1.8 | 10.90 |
| 3MESH | 1.6 | 6.866 |
| 4MESH | 1.2 | 5.15 |
| 5MESH | 0.91 | 4.17 |
| 6MESH | 0.80 | 3.433 |
| 8MESH | 0.60 | 2.575 |
| 10MESH | 0.55 | 1.990 |
| 12MESH | 0.50 | 1.616 |
| 14MESH | 0.45 | 1.362 |
| 16MESH | 0.40 | 1.188 |
| 18MESH | 0.35 | 1.061 |
| 20MESH | 0.30 | 0.970 |
| 26MESH | 0.28 | 0.696 |
| 30MESH | 0.25 | 0.597 |
| 40MESH | 0.21 | 0.425 |
| 50MESH | 0.19 | 0.318 |
| 60MESH | 0.15 | 0.273 |
| 70MESH | 0.14 | 0.223 |
| 80MESH | 0.12 | 0.198 |
| 90MESH | 0.11 | 0.172 |
| 100MESH | 0.10 | 0.154 |
| 120MESH | 0.08 | 0.132 |
| 140MESH | 0.07 | 0.111 |
| 150MESH | 0.06 | 0.109 |
| 160MESH | 0.06 | 0.099 |
| 180MESH | 0.053 | 0.088 |
| 200MESH | 0.053 | 0.074 |
| 250MESH | 0.04 | 0.062 |
| 300MESH | 0.035 | 0.050 |
| 325MESH | 0.03 | 0.048 |
| 350MESH | 0.03 | 0.043 |
| 400MESH | 0.025 | 0.0385 |
| 500MESH | 0.025 | 0.0258 |
| 635MESH | 0.020 | 0.020 |
| Width 0.4m-8m | ||
